FSY/ZH-90 90℃ PVC Flame Retardant Anti-Rodent Anti-Termite Soft Sheath Plastic

FSY/ZH-90 90℃ PVC Flame Retardant Anti-Rodent Anti-Termite Soft Sheath Plastic is a high-performance protective material. It has high temperature resistance and can maintain stable performance at high temperatures of 90°C. It is suitable for cable and pipeline protection in various high temperature environments. It has flame retardant properties and can effectively reduce the risk of fire. Unique anti-rodent and anti-termite design prevents pests from causing damage to cables and pipes. This plastic material has a wide range of applications in construction, electricity, communications and other fields.

Wire and cable with rodent-proof, termite-proof PVC sheath

Environmentally friendly anti-rodent, anti-termite PVC sheath material for wire and cable is made of polyvinyl chloride resin as the base material, adding special plasticizers, special stabilizers, antioxidants and other additives, and mixing, plasticizing and granulating.

Model, brand, name, implementation standard and use

Model	trademark	Maximum core operating temperature (°C)	name	Enforce the standard	use
FH-70-P	7081	70	70°CPVC anti-rodent and anti-termite sheath material	GB/T8815-2008	It is used for 70°C PVC anti-rat and anti-termite wire and cable sheath
FH-90-P	9081	90	90°CPVC anti-rodent and anti-termite cladding material	GB/T8815-2008	It is used for 90°C PVC anti-rat and anti-termite wire and cable sheath material

Note: The relative density index and color are determined by the supply and demand sides through negotiation

Mechanical, physical and electrical properties

Pilot project	unit	Benchmark value
Pilot project	unit	7081	9081
Tensile strength	≥MPa	15.0	16.0
Tensile strain at break	≥%	180	180
Impact embrittlement temperature	≤°C	-25	-20
Volume resistivity at 20°C	≥Ω·m	1.0X108	1.0X109
Dielectric strength	≥MV/m	18	18
200°C thermal settling time	≥min	50	80
Heat-aging properties
Thermal aging temperature	℃	100±2	100±2
Thermal aging time	h	168	240
Tensile strength after aging The maximum rate of change in tensile strength	≥MPa	15.0	16.0
	≤%	±20	±20
Tensile strain at break after aging The maximum rate of change of tensile strain at break	≥%	180	180
	≤%	±20	±20
Loss of quality	≤g/m²	23	15
Anti-rodent performance	/	The protection level is remarkable, and the protection rate is ≥ 0.9	The protection level is remarkable, and the protection rate is ≥ 0.9
Termite resistance (test colony method)	/	Passed at the level	Passed at the level

Processing technology

Processed by general extruder, L/D≥20, the recommended setting temperature of each extruder is as follows

Zone	District 1	2nd arrondissement	3rd arrondissement	4th arrondissement	5th arrondissement	Die head
Temperature °C	140	160	170	175	180	175

Marking, packaging, transportation and storage

Logo: The packaging bag should be marked with: the name of the manufacturer, product variety and model, batch number, color, manufacturing date, net weight, this standard number, and affix the color mark;

Packing: (25.0±0.2) kg bag, polyethylene film inner bag, woven bag or kraft paper composite bag outer packaging, or other packaging quality (weight) quantity negotiated by both supply and demand;

Transportation and storage: cable materials should not be exposed to the sun and rain during transportation, and should be stored in a clean, cool, dry and ventilated warehouse.
